4CH POE NVR NVR-7504P-4K Support VGA, HDMI full HD output simultaneously; Support ONVIF; access third party; Support AHD, TVI ,CVI,CVBS,IPHD video input; Support Web, CMS, center platform management software XMEYE, provide SDK development; Support multiple cloud technology, network penetration, alarm information pushed to your phone and other functions; Support various mobile monitoring (iPhone, Android); Remote Access, With DNS (ARSP),easy to monitor remotely. Model No. NST-NVR7504P-4K System Main processor Hi3798M Operating system Embedded Linux System resource Simultaneous multi-channel real-time recording, playback, network operation, USB backup Interface Operation interface 16-bit true color graphic menu operation interface, support mouse operation Preview 1/4/8 Video Video input (IP) 4*4K/4*5M/4*4M /8*1080P Video standards PAL(625TVL,50f/s) ; NTSC(525TVL,60f/s) Forwarding bandwidth H.265/H.264 Display quality Max:4K Playback quality 4K/5M/4M/1080P Decode 1*4K/2*5M/4*4M/4*1080P Motion detection Depend on camera Audio Audio compression G.711A intercom Unsupport Record and playback Record mode Manual>Alarm>Video Detection>Continuous Local playback 1*4K/2*5M/4*4M/4*1080P Search mode Search by Time/Calendar/Event/Channel Storage and back up Record Storage HDD 、 network Backup mode Network backup, USB hard disk, USB burner, SATA burner Interface Video output 1ch HDMI HD output(can be extended to support VGA) Audio I/O 0/0 Alarm I/O 0/0 Network interface 1* 10M/100M Adaptive Ethernet port,4 POE ports USB interface 2*USB2.0 ports Hard disk 1*SATA(extensible 2 SATA interface) (Up to 8TB for each disk) other ONVIF Support PTZ control Control PTZ device by network Power supply 48V/1.5A Power Consumption <10W(Without HDD) Work environment Temperature:0℃- 55℃ , Humidity:10% – 90%RH , Atm:86kpa – 106kp Dimension L350*W275*H80MM Weight 1.6KG
